Hager 3 Pole 80A Main Switch With Red Toggle

Archi­tec­ture

• Number of poles 3

• Neutral posi­tion Without neutral

• Type of pole 3P

Install­a­tion, mounting

• Nominal tight­ening torque 3,60 - 3,60 Nm

• Type of bottom connec­tion for modular devices Screw terminal

Voltage

• Rated oper­a­tional voltage Ue 400 - 400 V

• Type voltage supply AC

• Rated insu­la­tion voltage Ui 440 V

• Rated impulse with­stand voltage Uimp 6000 V

Capa­city

• Number of modules 3

Safety

• Ingress Protec­tion (IP) class IP20

Frequency

• Frequency 50 - 60 Hz

Dimen­sions

• Height 83 mm

• Width 52,50 mm

• Depth 68 mm

Equip­ment

• Number of NO contacts 3

• Number of NC contacts 0

Use condi­tions

• Oper­ating temper­ature -20 - 70 °C

• Stor­age/trans­port temper­ature -40 - 80 °C

Connec­tion

• Cross-sec­tion flex­ible conductor 6 - 35 mm²

• Cross-sec­tion rigid conductor 6 - 50 mm²

Endur­ance

• Number of mech­an­ical oper­a­tions 40000

• Elec­trical durab­ility at nominal load in AC21 in oper­ating cycles 2500

• Elec­trical durab­ility at nominal load in AC22 in oper­ating cycles 2500

Power

• Total power loss under IN 8,10 W

• Power loss per pole at In 2,70 W

Connectivity

• Down connec­tion align­ment for modular devices Aligned terminal

• Top connec­tion align­ment for modular devices Aligned terminal
